gdf::Channel Class Reference

Representation of a channel (signal in GDF) More...

#include <Channel.h>

Public Member Functions
	Channel (const SignalHeader *sig_hdr, const size_t length)
	Constructor.
	Channel (const SignalHeader *sig_hdr)
	Constructor.
	Channel (const Channel &other)
	Copy Constructor.
virtual	~Channel ()
	Destructor.
void	clear ()
	Reset read and write positions.
void	addSamplePhys (const double value)
	Add a physical sample to the channel.
template<typename T >
void	addSampleRaw (const T rawval)
	Add a raw sample to the channel.
void	blitSamplesPhys (const double *values, size_t num)
	Blit a number of physical samples into channel.
template<typename T >
void	blitSamplesRaw (const T *values, size_t num)
	Blit a number of raw samples into channel.
void	fillPhys (const double value, size_t num)
	Fill a number of samples with the same physical value.
template<typename T >
void	fillRaw (const T value, size_t num)
	Fill a number of samples with the same raw value.
void	setSamplePhys (size_t pos, double value)
	set sample value
double	getSamplePhys (size_t pos)
	get sample value
void	deblitSamplesPhys (double *values, size_t start, size_t num)
	Blit a number of physical samples from channel to buffer.
template<typename T >
void	deblitSamplesRaw (T *values, size_t start, size_t num)
	Blit a number of raw samples from channel to buffer.
size_t	getFree ()
	Get number of free samples.
size_t	getWritten ()
	Get number of written samples.
uint32	getTypeID ()
	Get type of channel.
Friends
std::ostream &	operator<< (std::ostream &out, const Channel &c)
	Channel Serializer.
std::istream &	operator>> (std::istream &in, Channel &c)
	Channel Deserializer.

---

Detailed Description

Representation of a channel (signal in GDF)

Definition at line 35 of file Channel.h.

---

Constructor & Destructor Documentation

gdf::Channel::Channel

(

const SignalHeader *

sig_hdr

)

Constructor.

Channel length is initialized to channel's samples_per_record.

Definition at line 80 of file Channel.cpp.

---

Member Function Documentation

void gdf::Channel::addSamplePhys

(

const double

value

)

Add a physical sample to the channel.

value is scaled from [phys_min..phys_max] to [dig_min..dig_max] and converted to the channel's data type

Definition at line 205 of file Channel.cpp.

Here is the caller graph for this function:

template<typename T >

void gdf::Channel::addSampleRaw

(

const T

rawval

)

Add a raw sample to the channel.

value is converted to the channel's data type. but otherwise remains unmodified

Definition at line 119 of file Channel.h.

Here is the caller graph for this function:

void gdf::Channel::blitSamplesPhys	(	const double *	values,
		size_t	num
	)

Blit a number of physical samples into channel.

values are scaled from [phys_min..phys_max] to [dig_min..dig_max] and converted to the channel's data type

Definition at line 230 of file Channel.cpp.

Here is the call graph for this function:

Here is the caller graph for this function:

template<typename T >

void gdf::Channel::blitSamplesRaw	(	const T *	values,
		size_t	num
	)

Blit a number of raw samples into channel.

values are converted to the channel's data type but otherwise remains unmodified

Definition at line 142 of file Channel.h.

Here is the call graph for this function:

Here is the caller graph for this function:

void gdf::Channel::deblitSamplesPhys	(	double *	values,
		size_t	start,
		size_t	num
	)

Blit a number of physical samples from channel to buffer.

values are scaled from [dig_min..dig_max] to [phys_min..phys_max] and converted to double

Definition at line 334 of file Channel.cpp.

Here is the call graph for this function:

Here is the caller graph for this function:

void gdf::Channel::fillPhys	(	const double	value,
		size_t	num
	)

Fill a number of samples with the same physical value.

value is scaled from [phys_min..phys_max] to [dig_min..dig_max] and converted to the channel's data type

Definition at line 239 of file Channel.cpp.

template<typename T >

void gdf::Channel::fillRaw	(	const T	value,
		size_t	num
	)

Fill a number of samples with the same raw value.

value is converted to the channel's data type but otherwise remains unmodified

Definition at line 263 of file Channel.cpp.

---

The documentation for this class was generated from the following files:

• Channel.h
• Channel.cpp
