IDSerializerRapid Class Reference

TOBI iD concrete XML serializer. More...

#include <tobiid/IDSerializerRapid.hpp>

Inheritance diagram for IDSerializerRapid:

Collaboration diagram for IDSerializerRapid:

Public Member Functions
	IDSerializerRapid (IDMessage *const message=NULL, const bool indent=false, const bool declaration=false)
	Constructor.
virtual	~IDSerializerRapid (void)
	Destructor.
virtual std::string *	Serialize (std::string *buffer)
	Serializes to std::string.
virtual std::string *	Deserialize (std::string *const buffer)
	Deserializes from std::string.
Public Member Functions inherited from IDSerializer
	IDSerializer (void)
	Constructor.
	IDSerializer (IDMessage *const message)
	Constructor.
virtual	~IDSerializer (void)
	Destructor.
IDSerializer *	SetMessage (IDMessage *const message)
	Sets the associated IDMessage.
virtual std::string	SerializeCp (void)
	Serializes to std::string.
virtual void	DeserializeCp (const std::string &buffer)
	Deserializes from std::string.
virtual char *	SerializeCh (char *buffer, const unsigned int bsize)
	Serializes to a char array.
virtual const char *	DeserializeCh (const char *buffer, const unsigned int bsize)
	Deserializes from a char array.

Protected Attributes
bool	_indent
	Indentation flag.
bool	_declaration
	Declaration flag.

Additional Inherited Members
Public Attributes inherited from IDSerializer
IDMessage *	message
	Pointer to the associated IDMessage.

Detailed Description

TOBI iD concrete XML serializer.

Serializes an IDMessage to XML using RapidXML.

See Also

IDSerializer

Examples:

idserializerrapid.cpp, and tpidclient.cpp.

Definition at line 33 of file IDSerializerRapid.hpp.

Constructor & Destructor Documentation

IDSerializerRapid::IDSerializerRapid	(	IDMessage *const	message = NULL,
		const bool	indent = false,
		const bool	declaration = false
	)

Constructor.

• message Pointer to an IDMessage instance
• indent If true, the XML output will be indented
• declaration If true, the XML output will contain an XML declaration

Definition at line 35 of file IDSerializerRapid (In Konflikt stehende Kopie von Workstation 2012-10-21).cpp.

Member Function Documentation

std::string * IDSerializerRapid::Deserialize ( std::string *const  buffer )

virtual

Deserializes from std::string.

• buffer Pointer to the std::string that contains the result of a serialization and that will be used for the deserialization

  Returns

  A pointer to the buffer instance

Implements IDSerializer.

Examples:

idserializerrapid.cpp.

Definition at line 107 of file IDSerializerRapid (In Konflikt stehende Kopie von Workstation 2012-10-21).cpp.

Here is the call graph for this function:

Here is the caller graph for this function:

std::string * IDSerializerRapid::Serialize ( std::string *  buffer )

virtual

Serializes to std::string.

• buffer Pointer to the std::string that will contain the result of the serialization

  Returns

  Pointer to the buffer instance

Implements IDSerializer.

Examples:

idserializerrapid.cpp.

Definition at line 49 of file IDSerializerRapid (In Konflikt stehende Kopie von Workstation 2012-10-21).cpp.

Here is the call graph for this function:

Here is the caller graph for this function:

---

The documentation for this class was generated from the following files:

• tobiid/IDSerializerRapid.hpp
• tobiid/IDSerializerRapid (In Konflikt stehende Kopie von Workstation 2012-10-21).cpp
• tobiid/IDSerializerRapid.cpp
